Moling is a trenchless pipe repair method that pulls a new pipe through the ground using a small entry and exit pit, leaving a driveway, patio or lawn largely undisturbed. Excavation means digging a full trench along the pipe run. Moling works well for straight, accessible runs once the leak is pinpointed precisely; excavation is still needed where the ground is too obstructed, the pipe is badly collapsed, or the route isn't straight enough.
In This Guide
What moling actually is
Moling pipe repair uses a machine, sometimes called a pipe bursting or pipe pulling mole, to drag a new pipe through the ground along roughly the same line as the old one. It typically needs a small entry pit at one end of the run and an exit pit at the other, rather than a trench dug the whole way between them.
The name comes from how the equipment moves underground, tunnelling through soil in a fairly straight line, similar to how a mole burrows. It's a trenchless technique, meaning the surface above the pipe, whether that's a driveway, a lawn or a path, stays mostly intact.
How the moling process works
Once the leak has been located precisely, a contractor digs two small pits: one at the start of the run and one at the end. A cable or rod is fed between the two pits, often through the old pipe or alongside it, and a new pipe is either pulled through behind a bursting head that breaks up the old pipe as it goes, or drawn through a pilot bore created specifically for the new line.
The two pits get reinstated once the new pipe is connected and pressure-tested, and the surface in between, tarmac, block paving, grass, is left as it was, aside from the two access points.
Step 1: Confirm the exact leak point and pipe run
Precise detection comes first, always. Moling depends on knowing the pipe's route and condition before any ground gets touched.
Step 2: Dig the entry and exit pits
Two small excavations, usually no bigger than needed for the equipment and access, replace what would otherwise be a full trench.
Step 3: Pull the new pipe through
The new pipe is drawn along the route between the two pits, following the line of the original pipe as closely as possible.
Step 4: Connect, test and reinstate
The new pipe is connected at both ends, pressure-tested, and the two small pits are filled and made good, leaving the rest of the surface untouched.
When excavation is still the better option
Moling isn't always possible. A pipe run with sharp bends doesn't suit a technique built around pulling a fairly straight new pipe through the ground. Heavily obstructed ground, packed with other services, tree roots or large stones, can also make it impractical or risky to mole through safely.
A badly collapsed or crushed pipe sometimes needs full excavation too, since there has to be enough of the old pipe's line left intact to guide the new one through. And where the pipe run needs to change direction, size, or connect to new fittings partway along, open-cut excavation gives a contractor direct access to do that properly. A larger supply run is a good example: our water mains leak detection work often turns up exactly this kind of pipe, where the fitting and valve layout needs full access rather than a pulled-through repair.
Choosing moling because it sounds less disruptive, without confirming the ground and pipe route actually suit it, can cause more problems than it solves. A proper site assessment before choosing the method saves time and cost either way.
Why detection has to come first
Neither method should start without knowing exactly where the leak is and how the pipe runs. Digging blind, whether by trench or by moling pits, risks missing the actual problem entirely or damaging a section of pipe that didn't need touching.
This is where underground water leak detection earns its place before any digging happens. Acoustic listening equipment can pick up the sound of water escaping a pressurised pipe from the surface, without breaking ground at all, and tracer gas, a safe mix of hydrogen and nitrogen pushed through the pipe, can be traced with a sensitive probe to confirm the exact point.
Listening before digging
An acoustic survey across a driveway or garden narrows a leak down to a specific spot, often within a metre or two, before any pit gets dug at all. That precision is what makes moling viable rather than a gamble.
Also relevant here is our guide on locating underground water pipes, which covers how a pipe run gets mapped before any repair method gets chosen.
Driveways, patios and mature gardens
The appeal of moling is obvious once you've seen the alternative. A full excavation along a driveway means lifting block paving or breaking up tarmac the whole length of the run, then relaying it afterwards, which adds cost and time on top of the actual pipe repair.
Mature gardens are similar. A trench through an established lawn or flower bed can take years to fully recover, and any trees or shrubs near the pipe run are at risk from root disturbance during a full dig. Moling's two small pits leave the rest of the garden essentially undisturbed.
Got a leak under the driveway or garden
We pinpoint the exact leak location with acoustic and tracer gas methods first, so a contractor can choose moling or excavation with confidence, not guesswork.
Moling vs excavation, side by side
Both methods fix the same underlying problem, a failed or leaking underground pipe, but the way they get there differs enough to matter for cost, disruption and timescale.
Moling
- Two small pits instead of a full trench
- Driveway, patio or lawn stays mostly intact
- Often quicker where ground conditions suit it
Excavation
- Needed for sharp bends or badly collapsed pipe
- Full trench means more reinstatement work
- Gives direct access to change pipe route or fittings
| Factor | Moling | Excavation |
|---|---|---|
| Ground disturbance | Two small pits | Full trench along the run |
| Best suited to | Straight, accessible runs | Bends, collapsed pipe, obstructed ground |
| Reinstatement | Minimal, two access points | Full surface repair along the trench |
| Precision needed first | Very high | High, but slightly more tolerant |
We see this most weeks with driveway leaks: a homeowner assumes the whole drive needs lifting, and a precise survey shows the pipe runs in a fairly straight line, well clear of the drainage and cabling nearby, which makes moling a realistic option.
What to ask a contractor before choosing
Ask exactly how the leak location was confirmed before any digging starts, and whether that survey covered the full pipe run or just the immediate leak point. A contractor recommending moling should be able to explain why the route suits it, not just that it's the less disruptive option in general.
It's also worth asking what happens if moling hits an obstruction partway through, since a plan that switches to excavation partway is very different from one that assumed moling would work from the outset.
- Confirm the leak location first. Acoustic or tracer gas detection, not guesswork.
- Check the pipe run for bends. Moling suits straight lines far better than sharp turns.
- Ask about ground conditions. Other services, tree roots or large stones can rule moling out.
- Get a contingency plan. Know what happens if moling can't complete the run.
- Compare reinstatement costs. Two small pits versus a full trench changes the total price significantly.
Frequently Asked Questions
Moling is a trenchless method that pulls a new pipe through the ground between two small pits, rather than digging a full trench along the entire run. It's used to replace a damaged or leaking underground pipe while leaving most of the surface above it, such as a driveway or lawn, largely undisturbed.
It depends on the job, but moling often reduces reinstatement costs since there's no full trench to refill and no driveway, patio or lawn to relay. Ground conditions and pipe route still determine whether moling is possible at all, so cost comparisons only make sense once a site survey confirms it's suitable.
Yes, moling is commonly used under driveways precisely because it avoids lifting block paving or breaking up tarmac along the whole pipe run. It needs a fairly straight route and ground reasonably free of major obstructions to work well.
Moling suits straight or gently curved pipe runs in reasonably clear ground. Sharp bends, badly collapsed pipe, or ground packed with other services, tree roots or large stones can make it impractical, in which case excavation remains the more reliable option.
Yes. Moling depends on knowing the exact pipe route and leak location beforehand, since the whole point is avoiding a full trench dig. Acoustic listening or tracer gas detection confirms the precise spot and route before any pits are dug.
Moling is often quicker where ground conditions suit it, since there's no lengthy trench to dig and refill. Excavation timescales depend heavily on the length of the run and how much reinstatement work is needed afterwards, so it varies from job to job.
